15 Ton Swing Arm Press Single Phase
Machine Specs



Swing Arm Clicker Press by CJRTec Distributing
Swing Arm by CJRTec Distributing
Swing Arm Clicker Press by CJRTec Distributing
Swing Arm press applications
Swing Arm press applications



What is a Swing Arm Press?



With the rising demand for more efficient manufacturing process, CJRTec offers you the line of Swing Arm Press machines. A Swing Arm Press is a type of clicker press machine (or clicking press to some) that is the simplest among other kinds of clicker press for sale, i.e. travel head press, receding head press, rotary press, kiss cutting press and others. It is used in cutting thin, flexible materials like rubber, plastic, fiberglass, and carbon fiber. It is easy enough to operate and, most of all, SAFE. The head of this type of clicker press can be moved to the side in order to get the cut dies, or put into position the other dies you're going to cut.

Our Swing Arm Press comes with one (1) year FULL WARRANTY. CJRTec sells brand new precision presses, wherein the availability of spare parts is always guaranteed. There are also a number of competent engineers on standby, ready to assist you with any problems arising from your use of our machine. CJRTec also provide test cuts to make sure that the machine will work with your chosen material and die.

Feel free to drop us a line with any inquiries that you may have.



Clicker Press Machine Specs



Table Dimension:16.0 " 35.4
Swing Arm Dimension:13.7 " 20.0
Stroke1.5 - 5.0
Daylight5.0
Power1Phase - 220v 60Hz
Cutting Speed0.08 m/s
RPM1700 r/min
Motor Power1.5 HP
Operating Amps7.21 A
Startup Amps28.4 - 50.5 A
Electric Cord2.5 mm≤
Weight1036 lbs
Dimension35.4 x 33.5 x 53.0
Shipping Dimensions37.8 x 35.4 x 61.0


Single Phase Terms:Download PDF

Included
1 Year Warranty
Vibration Control Pads

Video:View Here
Hydraulic Oil (not included):ISO 68
Operation Manual:PDF
Replacement Parts:Next Day Shipping
Extended Warranty:Optional



Watch videos of our Clicker Press in action



15 Ton Swing Arm Press
Single Phase


Machine Type Swing Arm
Tonnage 15
Model 15-SA-M-W-N
