Take full advantage of automation.
Get the most out of your manufacturing business through CJRTec Automated Engineering.
Calculate the tonnage you need here.
60-DAY BUILD | IN STOCK | |
| More Details | ||
| Model Number: | 10-SA-M-J-N | |
| Standard | Metric | |
| Maximum Cutting Force: | 10 Ton | |
| Cutting Table: | 16.0 | 406 mm |
| Swing Arm Dimension: | 13.7 | 348 mm |
| Stroke: | 1.5 - 5.0 | 38 - 127 mm |
| Daylight: | 5.0 | 127 mm |
| Power: | 1Phase - 220V 60Hz | |
| Cutting Speed: | 0.08 m/s | 0.26 ft./s |
| RPM: | 1700 r/min | |
| Motor Power: | 1.5 HP | 2kW |
| Operating Amps: | 7.21 A | |
| Startup Amps: | 28.4 - 50.5 A | |
| Electric Cord: | 2.5 mm² | |
| Weight: | 838 lbs | 380 kg |
| Dimension: | 31.5 x 30.7 x 49.0 | 800 x 780 x 1245 mm |
| Shipping Dimension: | 32.0 x 33.0 x 57.0 | 813 x 838 x 1448 mm |
| Single Phase Terms: | Download | |
| Included | ||
| Vibration Control Pads | ||
| Video: | View Here | |
| Operation Manual: | ||
| Shipping Included: | No | |
| Extended Warranty: | Optional | |
| Replacement Parts: | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| More Details | ||
| Model Number: | 10-SA-M-J-N | |
| Standard | Metric | |
| Cutting Table: | 16.0 | 406 mm |
| Swing Arm Dimension: | 13.7 | 348 mm |
| Stroke: | 5-65mm | 127 - 1651 mm |
| Daylight: | 5.0 | 127 mm |
| Power: | 3Phase - 220V 60HZ | |
| Cutting Speed: | 0.08 m/s | 0.26 ft./s |
| RPM: | 1730 r/min | |
| Motor Power: | 1 HP | 1kW |
| Operating Amps: | 2.93 A | |
| Startup Amps: | 11.7 - 20.5 A | |
| Electric Cord: | 1.5 mm² | |
| Weight: | 380kgs | 172 kg |
| Dimensions: | 31.5 x 30.7 x 49.0 | 800 x 780 x 1245 mm |
| Shipping Dimension: | 32.0 x 33.0 x 57.0 | 813 x 838 x 1448 mm |
| Included | ||
| Vibration Control Pads | ||
| Video: | View Here | |
| Operation Manual: | ||
| Shipping Included: | No | |
| Extended Warranty: | Optional | |
| Replacement Parts: | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| More Details | ||
| Model Number: | 15-SA-M-J-N | |
| Standard | Metric | |
| Table Dimension: | 16.0 | 406 mm |
| Swing Arm Dimension: | 13.7 | 348 mm |
| Stroke | 1.5 - 5.0 | 38 - 127 mm |
| Daylight | 5.0 | 127 mm |
| Power | 1Phase - 220v 60Hz | |
| Cutting Speed | 0.08 m/s | 0.26 ft./s |
| RPM | 1700 r/min | |
| Motor Power | 1.5 HP | 2kW |
| Operating Amps | 7.21 A | |
| Startup Amps | 28.4 - 50.5 A | |
| Electric Cord | 2.5 mm² | |
| Weight | 1036 lbs | 470 kg |
| Dimension | 35.4 x 33.5 x 53.0 | |
| Shipping Dimensions | 37.8 x 35.4 x 61.0 | 960 x 899 x 1549 mm |
| Single Phase Terms: | Download | |
| Included | ||
| Vibration Control Pads | ||
| Video: | View Here | |
| Hydraulic Oil (not included): | ISO 68 | |
| Operation Manual: | ||
| Replacement Parts: | Next Day Shipping | |
| Extended Warranty: | Optional | |
60-DAY BUILD | IN STOCK | |
| More Details | ||
| Model Number: | 15-SA-M-J-N | |
| Standard | Metric | |
| Cutting Table: | 16.0 | 406 mm |
| Swing Arm Dimension: | 13.7 | 348 mm |
| Stroke: | 1.5 - 5.0 | 38 - 127 mm |
| Daylight: | 5.0 | 127 mm |
| Power: | 3 Phase 220v 60hz | |
| Cutting Speed: | 0.08 m/s | 0.26 ft./s |
| RPM: | 1730 r/min | |
| Motor Power: | 1.5 HP | 2kW |
| Operating Amps: | 4.49 A | |
| Startup Amps: | 18.0 - 22.5 A | |
| Electric Cord: | 2.5 mm² | |
| Weight: | 1036 lbs | 470 kg |
| Dimension: | 35.4 x 33.5 x 53.0 | 899 x 851 x 1346 mm |
| Shipping Dimensions: | 37.8 x 35.4 x 61.0 | 960 x 899 x 1549 mm |
| Included | ||
| Vibration Control Pads | ||
| Video: | ||
| Operation Manual: | ||
| Shipping Included: | No | |
| Extended Warranty: | Optional | |
| Replacement Parts: | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| More Details | ||
| Model Number: | 20-SA-M-J-N | |
| Standard | Metric | |
| Cutting Table: | 18 3/4 | 457 mm |
| Swing Arm Dimension: | 19 7/8 | 483 mm |
| Stroke: | 1.5 - 5.0 | 38 - 127 mm |
| Daylight: | 5.0 | 127 mm |
| Power: | 3PHASE 220V 60Hz. | |
| Cutting Speed: | 0.08 m/s | 0.26 ft./s |
| RPM: | 1730 r/min | |
| Motor Power: | 2 HP | 3kW |
| Operating Amps: | 5.86 A | |
| Startup Amps: | 23.4 - 41.0 A | |
| Electric Cord: | 2.5 mm² | |
| Weight: | 1367 lbs | 620 kg |
| Dimension: | 39.0 x 38.6 x 56.0 | 991 x 980 x 1422 mm |
| Shipping Dimension: | 43.0 x 43.0 x 65.0 | 1092 x 1092 x 1651 mm |
| Included | ||
| Vibration Control Pads | ||
| Video: | View Here | |
| Operation Manual: | ||
| Shipping Included: | No | |
| Extended Warranty: | Optional | |
| Replacement Parts: | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| More Details | ||
| Model Number: | 27-SA-M-J-N | |
| Standard | Metric | |
| Swing Arm Dimension: | 20.0 | 508 mm |
| Table Dimension: | 39.0 | 991 mm |
| Stroke: | 1.5 - 5.0 | 38 - 127 mm |
| Daylight: | 5.0 | 127 mm |
| Power: | 3Phase 220V 60Hz | |
| Cutting Speed: | 0.08 m/s | 0.26 ft./s |
| RPM: | 1730 RPM | |
| Motor Power: | 3 HP | 4kW |
| Operating Amps: | 8.5 A | |
| Startup Amps: | 34.0 - 59.5 A | |
| Electric Cord: | 2.5 mm² | |
| Weight: | 1807 lbs | 820 kg |
| Dimension: | 47.2 x 40.0 x 54.0 | 1199 x 1016 x 1372 mm |
| Shipping Dimension: | 53.0 x 46.5 x 62.0 | 1346 x 1181 x 1575 mm |
| Included | ||
| Vibration Control Pads | ||
| Video: | View Here | |
| Operational Manual: | ||
| Shipping Included: | NO | |
| Extended Warranty: | Optional | |
| Replacement Parts: | Next Day Shipping | |
 swing arm 2020_600px.webp "Swing Arm Press 9")
60-DAY BUILD | IN STOCK | |
| More Details | ||
| Model Number: | 27-SA-M-J-N | |
| Standard | Metric | |
| Table Dimension: | 47.0 | 1194 mm |
| Swing Arm Dimension: | 20.0 | 508 mm |
| Stroke: | 1.5 - 5.0 | 38 - 127 mm |
| Daylight: | 5.0 | 127 mm |
| Power: | 3 Phase 220v 60hz | |
| Cutting Speed: | 0.08 m/s | 0.26 ft./s |
| RPM: | 1730 r/min | |
| Motor Power: | 3 HP | 4kW |
| Operating Amps: | 8.5 A | |
| Startup Amps: | 34.0 -59.5 A | |
| Electric Cord: | 2.5 mm² | |
| Weight: | 2006 lbs | 910 kg |
| Dimension: | 47.2 x 40.0 x 54.0 | 1199 x 1016 x 1372 mm |
| Shipping Dimensions | 53.0 x 46.5 x 62.0 | 1346 x 1181 x 1575 mm |
| Included | ||
| 1 Year Warranty | ||
| Vibration Control Pads | ||
| Video: | View Here | |
| Operation Manual: | ||
| Extended Warranty: | Optional | |
| Replacement Parts: | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 20-SA-A-J-N | |
| Standard | Metric | |
| Minimum Cutting Force: | 8 Ton | |
| Swing Arm Dimension: | 14.0 | 356 mm |
| Stroke Adjustment: | 0.0 - 2.36 | 0 - 60 mm |
| Range between the worktables: | 0.0 - 2.0 | 0 - 51 mm |
| Cutting Speed: | 0.08 m/s | 0.26 ft./s |
| Motor Size: | 1.5 HP | 2kW |
| Power requirement: | 3ph 220V 60HZ | |
| Electric Cord: | 5' | |
| Operating Amps: | 4 | |
| Startup Amps: | 21 | |
| RPM: | 1730 | |
| Cutting speeds available: | Up to 24 IPS | |
| Table Diameter: | 33.0 | |
| Video: | View Here | |
| Hydraulic Oil (not included): | ISO 68 | |
| Total Weight: | 1800 lbs | |
| Shipping Dimension: | 48.0 | 1219 mm |
| Dimension: | 42.0 | 1067 mm |
| Operation Manual: | ||
| Replacement parts: | Next day delivery | |
| Shipping Included: | NO | |
| Extended Warranty: | Optional | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 27-KSP-M-J-N | |
| Standard | Metric | |
| Table: | 29.5 | 749 mm |
| Osha Cover: | YES | |
| Creasing and Cutting Speed: | 25±3 Stride/min | |
| Feeding Mode: | Manual | |
| Motor: | 3 HP | |
| Power: | 220v 3pH 60hz | |
| RPM: | 960 | |
| Adjustment Variable Between Bases: | 0.0 - 0.24 | 0 - 6 mm |
| Creasing and Cutting Knife Line Area: | <15 m | |
| Video: | View Here | |
| Hydraulic Oil (Not Included): | ISO 68 | |
| Net Weight of Machine: | 3968 lbs | 1800 kg |
| Overall Dimensions: | 53 x 59 x 63 | 1346 x 1499 x 1600 mm |
| Crate Dimensions: | 63 x 69 x 73 | 1600 x 1753 x 1854 mm |
| Crated Weight | 4300 lbs | 1950 kg |
60-DAY BUILD | IN STOCK | |
| Model Number: | 25-TH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 0.0 | 0 mm |
| Range between the working tables: | 1.8 | 46 mm |
| Size of the upper pressing board: | 19.7 | 500 mm |
| Size of lower worktable: | 63.0 | 1600 mm |
| Motor power: | 3 HP | 4kW |
| Power Requirement: | 3PHASE 220V 60Hz | |
| Startup Amps: | 20 | |
| Operating Amps: | 4 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Overall dimension: | 90 x 32 x 89 | 2286 x 813 x 2261 mm |
| Total weight: | 4188 lbs | 1900 kg |
| Video: | View Here | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Shipping Cost: | Not Included | |
| Shipping Responsibility: | Buyer's | |
| Extended Warranty: | Optional | |
| Optional Equipment | ||
| Automatic Roll feed | Light Curtain | |
| Semi Auto Roll feed | Laser Marking System | |
| Single Roll stand | Table Randomizer | |
| Multi Roll Stand | Die Clamping System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 25-TH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 0.0 | 0 mm |
| Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
| Range between the working tables: | 1.18 | 30 mm |
| Size of Traveling Head Base: | 19.7 | |
| Size of lower worktable: | 63.0 | 1600 mm |
| Auto Side Movement: | YES | |
| Motor: | 4 HP | |
| Power Requirement: | 3PHASE 220V 60Hz | |
| Startup Amps: | 20 | |
| Operating Amps: | 4 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Overall Dimension: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
| Crate Size: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
| Total weight: | 3747 lbs | 1700 kg |
| Video: | View Here | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Shipping: | Not Included | |
| Shipping Responsibility: | Buyer's | |
| Extended Warranty: | Optional | |
| Optional Equipment | ||
| Automatic Roll feed | Light Curtain | |
| Semi Auto Roll feed | Laser Marking System | |
| Single roll stand | Table Randomizer | |
| Multi Roll Stand | Die Clamping System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 25-TH-M-J-Y | |
| Standard | Metric | |
| Travel adjustment range: | 1.0 | 25 mm |
| Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
| Range between the working tables: | 1.18 | 30 mm |
| Size of Traveling Head Base: | 19.7 | |
| Size of lower worktable: | 82.0 | 2083 mm |
| Motor: | 3 HP | |
| Power Requirement: | 3PHASE 220V 60Hz | |
| Startup Amps: | 20 | |
| Operating Amps: | 4 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Overall Dimension: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
| Crate Size: | 98 x 29 x 84 | 2489 x 737 x 2134 mm |
| Total weight: | 3918 lbs | 1777 kg |
| Video: | View Here | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Shipping Cost: | Not Included | |
| Shipping Responsibility: | Buyer's | |
| Extended Warranty: | Optional | |
| Optional Equipment | ||
| Automatic Roll feed | Light Curtain | |
| Semi Auto Roll feed | Laser Marking System | |
| Single Roll stand | Table Randomizer | |
| Multi Roll Stand | Die Clamping System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 25-TH-A-J-N | |
| Standard | Metric | |
| Head Size: | 20.0 | 508 mm |
| Lower Table Size: | 63.0 | 1600 mm |
| Travel adjustment range: | 1.2 - 6.0 | 30 - 152 mm |
| Up and Down Speed: | 4.75 in/s | 0.4 ft./s |
| Side to Side Speed: | 9 in/s | 0.75 ft./s |
| Motor Size: | 4 HP | 5kW |
| Power Requirements: | 220v 3Phase 60Hz | |
| Startup Amps: | 15 | |
| Running Amps: | 5 | |
| RPM: | 1680 | |
| Power Cord: | 10 ft | |
| Overall Dimensions: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
| Shipping Dimensions: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
| Weight: | 4630 lbs | 2100 kg |
| Video: | View Here | |
| Operation Manual: | ||
| Replacement Parts: | Next Day Shipping | |
| Extended Warranty: | Optional | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 25-TH-A-J-Y | |
| Standard | Metric | |
| Range between the working tables: | 1.18 | 30 mm |
| Travel adjustment range: | 0.0 | 0 mm |
| Size of Traveling Head Base: | Diameter of 16 .0 | |
| Size of lower worktable Depth: | 62.0 x 19.5 | |
| Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
| Side to Side Speed: | 2 - 9 in/s | 2.42 ft./s |
| Feeding Speed: | 3/4 - 3.5 in/s | |
| Motor: | 4 HP | |
| Power Requirement: | 3PHASE 220V 60Hz | |
| Startup Amps: | 20 | |
| Operating Amps: | 4 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Total weight: | 4630 lbs | 2100 kg |
| Overall Dimension: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
| Crate Size: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
| Video: | View Here | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Extended Warranty: | Optional | |
| Key Features | ||
| Single or Multi layer cutting | Programmable automatic head movement | |
| Auto roll advancement | Programmable Nesting feature | |
| Cutting pad lock | Cut and hold feature for heat press capabilities | |
| High speed movement | Fast magnetic die setup feature | |
| Light Curtain | Up down speed control | |
| Optional Equipment | ||
| Automatic Roll feed | Light Curtain | |
| Semi Auto Roll feed | Laser Marking System | |
| Single Roll stand | Table Randomizer | |
| Multi Roll Stand | Die Clamping System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 30-TH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 0.0 | 0 mm |
| Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
| Range between the working tables: | 1.18 | 30 mm |
| Size of traveling head: | 22.5 x 22.5 | 572 x 572 mm |
| Size of lower worktable: | 63.0 x 23.5 | 1600 x 597 mm |
| Auto Side Movement: | YES | |
| Motor power: | 3 HP | 4kW |
| Power Requirement: | 3PHASE 220V 60Hz | |
| Startup Amps: | 20 | |
| Operating Amps: | 4 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Overall dimension: | 91 x 42 x 77 | 2311 x 1067 x 1956 mm |
| Crate Size: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
| Total weight: | 3747 lbs | 1700 kg |
| Video: | View Here | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Shipping Cost: | Not Included | |
| Shipping Responsibility: | Buyers | |
| Extended Warranty: | Optional | |
| Optional Equipment | ||
| Automatic Roll feed | Light Curtain | |
| Semi Auto Roll feed | Laser Marking System | |
| Single roll stand | Table Randomizer | |
| Multi Roll Stand | Die Clamping System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 35-TH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 0.0 | 0 mm |
| Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
| Range between the working tables: | 1.2 | 30 mm |
| Size of traveling head: | 19.5 | 495 mm |
| Size of lower worktable: | 62.0 | 1575 mm |
| Auto Side Movement: | YES | |
| Motor power: | 4 HP | 5kW |
| Power Requirement: | 3PHASE 220V 60Hz | |
| Startup Amps: | 20 | |
| Operating Amps: | 4 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Fluorescent Table Light: | Yes | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Overall dimension: | 79 x 29 x 80 | 2007 x 737 x 2032 mm |
| Crate Size: | 86 x 35 x 86 | 2184 x 889 x 2184 mm |
| Total weight: | 5291 lbs | 2400 kg |
| Video: | View Here | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Shipping Cost: | Not Included | |
| Shipping Responsibility: | Buyer's | |
| Extended Warranty: | Optional | |
| Optional Equipment | ||
| Automatic Roll feed | Light Curtain | |
| Semi Auto Roll feed | Laser Marking System | |
| Single roll stand | Table Randomizer | |
| Multi Roll Stand | Die Clamping System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 35-TH-A-J-N | |
| Standard | Metric | |
| Range Between Working Tables: | 1.0 | 25 mm |
| Travel Adjustment Range: | 0.0 | 0 mm |
| Size of Travel Head: | 19.5 | 495 mm |
| Size of Lower Work Table: | 63.0 | |
| Motor Power: | 4 HP | 5kW |
| Power Requirements: | 3Phase 220v 60Hz | |
| Startup Amps: | 42 | |
| Operating Amps: | 14 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Hydraulic Fluid (not included): | ISO 68 | |
| Weight | 0 kg | |
| Dimension | ||
| Video: | View Here | |
| Operation Manual: | ||
| Replacement Parts: | Next Day Shipping | |
| Extended Warranty: | Optional | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 50-TH-A-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 0.0 | 0 mm |
| Range between working tables: | 1.0 | 25 mm |
| Size of traveling head: | 24.0 | 610 mm |
| Size of lower work table: | 72.0 | 1829 mm |
| Motor power: | 7.25 HP | 10kW |
| Power Requirement: | 3PHASE220V60Hz. | |
| Startup Amps: | 75 | |
| Operating Amps: | 19 | |
| RPM: | 1680 | |
| Power Cord: | 5' | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Net weight(Dry): | 8378 lbs | 3800 kg |
| Shipping weight : | 8819 lbs | 4000 kg |
| Dimension | 102 x 71 x 87 | |
| Video: | View Here | |
| Training Video: | Yes | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Shipping Cost: | Not Included | |
| Shipping Responsibility: | Buyers | |
| Extended Warranty: | Optional | |
| Key Features | ||
| Single or Multi layer cutting | Die Clamping System | |
| Auto roll advancement | Up down speed control | |
| Cutting pad lock to prevent pad warping | ||
| Programmable automatic head movement. | ||
| Programmable Nesting feature | Light Curtain | |
| Cut and hold feature for heat press capabilities | ||
| High speed movement | ||
| Optional Equipment | ||
| Single Roll stand | Laser Marking System | |
| Multi Roll Stand | Table Randomizer | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 70-TH-M-J-N | |
| Standard | Metric | |
| Table size: | 63.0 | 1600 mm |
| Head size: | 24.0 | 610 mm |
| Distance between tables: | 0.0 | |
| Travel adjustment range: | 0.0 | 0 mm |
| Motor: | 7.25hp | |
| Power Requirement: | 220v 3ph 60Hz | |
| Startup Amps: about | 25A | |
| Operating Amps: about | 18A | |
| RPM: | 970 r/m | |
| Shipping weight: | 16534 lbs | 7500 kg |
| Dimensions: | 0 mm | |
| Video: | View Here | |
| Training Video: | Yes | |
| Operation Manual: | ||
| Replacement Parts: | Next day shipping | |
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Shipping Cost: | Not Included | |
| Shipping Responsibility: | Buyer's | |
| Extended Warranty: | Optional | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 75-TH-A-J-N | |
| Standard | Metric | |
| CNC Auto Feed Table size: | 63.0 | |
| Head size: | 24.0 | 610 mm |
| Distance between tables: | 0.0 | |
| Travel adjustment range: | 0.0 | 0 mm |
| Motor: | 7.25 HP | |
| Power Requirement: | 220v 3ph 60Hz | |
| AUTO FEED SYSTEM | ||
| Abrasive Steel Rollers: | Diameter of 4.0 | |
| (Drive motor)Servo motor: | 1 HP | |
| Pneumatic Cyl 6.25 x 4QGS2 | 150 lbs Down Pressure | |
| Opening between rollers: | 2 | |
| Startup Amps: about | 25A | |
| Operating Amps: about | 18A | |
| RPM: | 970r/m | |
| Shipping weight: | 16534 lbs | 7500 kg |
| Dimensions: | 0 mm | |
| Video: | View Here | |
| Training Video: | Yes | |
| Operation Manual: | ||
| Hydraulic Fluid (Not Included): | ISO 68 | |
| Replacement Parts: | Next day shipping | |
| Shipping Cost: | Not Included | |
| Shipping Responsibility: | Buyer's | |
| Extended Warranty: | Optional | |
| Optional Equipment | ||
| Single Roll stand | Laser Marking Sys | |
| Multi Roll Stand | 480v motor | |
| 360 degree swivel head | ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 25-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 0.0 | 0 mm |
| Up/Down Travel Speed | 0.10m/s | 0.33 ft./s |
| Range between the working tables | 2.0 | 51 mm |
| Size of the upper pressing board | 63.0 | 1600 mm |
| Size of lower worktable | 63.0 | 1600 mm |
| Motor power | 3HP | 4kW |
| Power Requirement | 3PHASE220V60Hz. | |
| Option for Single Phase Power | YES + $830.00 | |
| Start up Amps | 20 amps | |
| Operating Amps | 4 amps | |
| Overall Dimension | 73.0 x 27.5 x 63.0 | 1854 x 699 x 1600 mm |
| Crate Dimension | 85.0 x 35.5 x 71.0 | 2159 x 902 x 1803 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Total weight | 3086 lbs | 1400 kg |
| Video | View Here | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Included | No | |
| Warranty | 1 Year | |
| Extended Warranty | Optional | |
| Optional Equipment | ||
| Automatic Roll feed | Light Curtain | |
| Semi Auto Roll feed | Laser Marking System | |
| Single roll stand | Table Randomizer | |
| Multi Roll Stand | Die Clamping System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 30-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 4.0 | 102 mm |
| Range between the working tables | 2 | 51 mm |
| Size of the upper pressing board: | 62 | 1575 mm |
| Size of lower worktable: | 62 | 1575 mm |
| Motor power: | 4 HP | 5kW |
| Power Requirement | 3PHASE220V60Hz. | |
| Startup Amps | 20 | |
| Operating Amps | 4 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Overall dimension: | 91 x 48 x 56 | 2311 x 1219 x 1422 mm |
| Total weight: | 4700 lbs | 2132 kg |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
| Optional Equipment | ||
| Multi Roll Stand | Single roll stand | |
| Table Randomizer | Light Curtain | |
| Die Clamping System | Laser Marking System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 30-BP-M-J-Y | |
| Standard | Metric | |
| Travel adjustment range: | 5.7 | 145 mm |
| Range between the working tables: | 2.3 | 58 mm |
| Size of the upper pressing board: | 62.0 | 1575 mm |
| Size of lower worktable: | 62 | 1575 mm |
| Motor power: | 3 hp | 4kW |
| Power Requirement | 3PHASE220V60Hz. | |
| Startup Amps | 20 | |
| Operating Amps | 4 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Overall dimension: | 90 x 46 x 65 | 2286 x 1168 x 1651 mm |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
| Optional Equipment | ||
| Multi Roll Stand | Single roll stand | |
| Table Randomizer | Light Curtain | |
| Die Clamping System | Laser Marking System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 30-BP-M-J-Y | |
| Standard | Metric | |
| Travel adjustment range: | 8.6 | 218 mm |
| Range between the working tables: | 2.3 | 58 mm |
| Size of the upper pressing board: | 62.0 | 1575 mm |
| Size of lower worktable: | 62 | 1575 mm |
| Motor power: | 3 hp | 4kW |
| Power Requirement | 3PHASE220V60Hz. | |
| Startup Amps | 20 | |
| Operating Amps | 4 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Overall dimension: | 90 x 46 x 65 | 2286 x 1168 x 1651 mm |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
| Optional Equipment | ||
| Multi Roll Stand | Single roll stand | |
| Table Randomizer | Light Curtain | |
| Die Clamping System | Laser Marking System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 30-BP-M-J-Y | |
| Standard | Metric | |
| Travel adjustment range: | 4.0 | 102 mm |
| Range between the working tables | 2.5 | 64 mm |
| Size of the upper pressing board: | 82.0 | 2083 mm |
| Size of lower worktable: | 82 x 20 | 2083 x 508 mm |
| Motor power: | 4 HP | 5kW |
| Power Requirement | 3PHASE 220V 60Hz | |
| Startup Amps | 20 | |
| Operating Amps | 4 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Overall dimension: | 91 x 48 x 56 | 2311 x 1219 x 1422 mm |
| Total weight: | 4700 lbs | 2132 kg |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
| Optional Equipment | ||
| Multi Roll Stand | Single roll stand | |
| Table Randomizer | Light Curtain | |
| Die Clamping System | Laser Marking System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 30-BP-A-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 4.0 | 102 mm |
| Range between the working tables | 2.5 | 64 mm |
| Size of the upper pressing board: | 63.0 | 1600 mm |
| Size of lower worktable: | 63 | 1600 mm |
| Motor power: | 4 HP | 5kW |
| Power Requirement | 3PHASE 220V 60Hz | |
| Startup Amps | 20 | |
| Operating Amps | 4 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Overall dimension: | 91 x 48 x 56 | 2311 x 1219 x 1422 mm |
| Total weight: | 4700 | 2132 kg |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
| Optional Equipment | ||
| Multi Roll Stand | Table Randomizer | |
| Light Curtain | Laser Marking System | |
| Die Clamping System | Single roll stand | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 35-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 4.0 | 102 mm |
| Range between the working tables | 2.5 | 64 mm |
| Size of the upper pressing board | 63.0 | 1600 mm |
| Size of lower worktable | 63 | 1600 mm |
| Motor power | 3 HP | 4kW |
| Power Requirement | 3PHASE220V60Hz. | |
| Power Cord | 5' | |
| Startup Amps | 26 | |
| Operating Amps | 5 | |
| Overall dimension | 84.5 x 45 x 59 | |
| Crate Demension | 85 x 35.5 x 71 | |
| Total weight | 4014 lbs | 1821 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 35-BP-A-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 4.0 | 102 mm |
| Range between the working tables: | 2.5 | 64 mm |
| Size of the upper pressing board: | 63.0 | 1600 mm |
| Size of lower worktable: | 63 | 1600 mm |
| Motor power: | 3kW 4hp | 4kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 20 | |
| Operating Amps | 4 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Overall dimension: | 90 x 51 x 87 | 2286 x 1295 x 2210 mm |
| Total weight: | 4960 lbs | 2250 kg |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 5 1/8 | 13157 mm |
| Range between the working tables | 7 3/32 | 178 mm |
| Size of the upper pressing board | 63.0 x 28.7 | 1600 x 729 mm |
| Size of lower worktable | 63 | 1600 mm |
| Motor power | 4 hp | 5kW |
| Power Requirement | 3PHASE220V60Hz. | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Startup Amps | 26 | |
| Operating Amps | 5 | |
| Overall dimension | 88.5 x 49.0 x 59.0 | |
| Posts | 4 | |
| Net Weight | 1750 kg | 794 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-BP-A-J-N | |
| Standard | Metric | |
| Travel adjustment range | 0 to 4.25 | 0 - 108 mm |
| Range between the working tables | 2.25 | 57 mm |
| Size of the upper pressing board | 63.0 | 1600 mm |
| Size of lower worktable | 63 | 1600 mm |
| Motor power | 4 hp | 5kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Startup Amps | 26 | |
| Operating Amps | 5 | |
| Overall dimension | 91 x 57 x 87 | |
| Posts | 4 | |
| Net Weight | 6700 lbs | 3039 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 50-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 5 1/8 | 13157 mm |
| Range between the working tables | 7 3/32 | 178 mm |
| Size of the upper pressing board | 63.0 x 31.5 | 1600 x 800 mm |
| Size of lower worktable | 63.0 x 31.5 | 1600 x 800 mm |
| Motor power | 6 HP | 8kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 75 A | |
| Operating Amps | 20 A | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Posts | 4 | |
| Overall dimension: | 92.5 x 55.0 x 61.0 | 2350 x 1397 x 1549 mm |
| Net Weight | 2350kg | 1066 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 60-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 5.0 | 127 mm |
| Range between the working tables | 7.5 | 191 mm |
| Size of the upper pressing board | 63.0 | 1600 mm |
| Size of lower worktable | 63.0 | 1600 mm |
| Motor power | 6HP | 8kW |
| Power Requirement | 3PHASE 220V 60Hz | |
| Startup Amps | 75 | |
| Operating Amps | 20 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Posts | 4 | |
| Overall dimension: | 87 x 53 x 71 | 2210 x 1346 x 1803 mm |
| Net Weight | 6666 lbs | 3024 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 70-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 5.0 | 127 mm |
| Range between the working tables | 2.0 | 51 mm |
| Size of the upper pressing board | 63.0 | 1600 mm |
| Size of lower worktable | 63.0 | 1600 mm |
| Motor power | 6HP | 8kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 75 | |
| Operating Amps | 20 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Posts | 4 | |
| Overall dimension | ||
| Net Weight | ||
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 80-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 0.0 | 0 mm |
| Range between the working tables | 2.0 | 51 mm |
| Size of the upper pressing board | 63.0 | 1600 mm |
| Size of lower worktable | 63.0 | 1600 mm |
| Motor power | 10 HP | 14kW |
| Power Requirement | 220V 3PHASE 60Hz | |
| Startup Amps | 75 | |
| Operating Amps | 20 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Posts | 4 | |
| Overall Dimension | 105.51 x 39.37 x 63.0 | 2680 x 1000 x 1600 mm |
| Net Weight | 13227.74 lbs | 6000 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| With pneumatic die clamps | ||
| Video: | View Here | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 80-BP-M-J-N | |
| Standard | Metric | |
| Lower Work Table | 63.0 | 1600 mm |
| Upper Beam | 63.0 | 1600 mm |
| Motor Size | 10 HP | 14kW |
| Power Requirement | 3Phase 220v 60Hz | |
| Starting Amps | 75 | |
| Running Amps | 23 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Post | 4 | |
| Net Weight | 10689 lbs | 4848 kg |
| Hydraulic Fluid (not included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next Day | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Optional Warranty | Up to 5 years | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 100-BP-M-J-N | |
| Standard | Metric | |
| Travel Adjustment Range: | 5.5 | 140 mm |
| Range between the working tables: | 1.9 | 48 mm |
| Size of Upper Pressing Board: | 63.0 x 48.0 | |
| Size of Lower Worktable: | 63.0 x 48.5 | |
| Motor Power: | 14.75 HP | 20kW |
| Power Requirement: | 220V 3Phase 60hz | |
| Startup Amps: | 75A | |
| Operating Amps: | 34A | |
| Power cord: | 5' | |
| Posts: | 4 | |
| Weight: | 15000 lbs | 6804 kg |
| Dimensions: | 106 x 70 x 70 | 2692 x 1778 x 1778 mm |
| Operational Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Optional Equipment | ||
| Table Randomizer | Multi Roll Stand | |
| Die Clamping System | Light Curtain | |
| Single Roll Stand | Laser Marking System | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 100-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 5.0 | 127 mm |
| Range between the working tables | 2.0 | 51 mm |
| Size of the upper pressing board | 63.0 x 31.5 | 1600 x 800 mm |
| Size of lower worktable | 63.0 x 32.0 | 1600 x 813 mm |
| Motor power | 6HP | 8kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 95 | |
| Operating Amps | 30 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Posts | 4 | |
| Overall dimension | ||
| Net Weight | ||
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 125-BP-M-J-N | |
| Standard | Metric | |
| Travel adjustment range | 5.0 | 127 mm |
| Range between the working tables | 2.0 | 51 mm |
| Size of the upper pressing board | 63.0 x 31.5 | 1600 x 800 mm |
| Size of lower worktable | 63.0 x 32.0 | 1600 x 813 mm |
| Motor power | 6HP | 8kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 75 | |
| Operating Amps | 20 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Posts | 4 | |
| Overall dimension: | 92.5 x 55.0 x 61.0 | 2350 x 1397 x 1549 mm |
| Net Weight | 7720 lbs | 3502 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video: | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 150-BP-M-J-N | |
| Standard | Metric | |
| Stroke range : | 0 | 0 mm |
| Range between the working tables : | 3.0 | 76 mm |
| Size of upper cutting board : | 58.0 x 43.25 | |
| Size of lower worktable : | 58.0 x 44.0 | |
| Motor power : | 14.75 HP | 20kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| PLC touching screen : | Weinview | |
| PLC : | Mitsubishi | |
| Net weight : | 11684 lbs | 5300 kg |
| Gross weight : | 12125 lbs | 5500 kg |
| Overall dimension: | 95 x 71 x 79 | 2413 x 1803 x 2007 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 200-BP-M-J-N | |
| Standard | Metric | |
| Stroke range : | 0 | 0 mm |
| Range between the working tables : | 2.0 | 51 mm |
| Size of upper cutting board : | 63.0 | |
| Size of lower worktable : | 63.0 x 40.0 | |
| Motor power : | 15hp | 21kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| PLC touching screen : | Weiview | |
| PLC : | Mitsubishi | |
| Net weight : | 15432 lbs | 7000 kg |
| Gross weight : | 16093 lbs | 7300 kg |
| Overall dimension: | 94 x 71 x 67 | 2388 x 1803 x 1702 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-RH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 4.3 | 109 mm |
| Range between the working tables: | 2 | 51 mm |
| Size of the upper pressing board: | 62.5 x 27.5 | 1588 x 699 mm |
| Size of lower worktable: | 62.5 x 27.9 | 1588 x 709 mm |
| Motor power: | 4HP | 5kW |
| Table Randomizer | YES | |
| Safety Light Curtain | YES | |
| RPM | - | |
| Power Cord | 5' | |
| Startup Amps | 26 | |
| Operating Amps | 5 | |
| Overall dimension: | - | 0 mm |
| Crate dimension | - | |
| Posts | 4 | |
| Net Weight | - | 0 kg |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-RH-M-J-Y | |
| Standard | Metric | |
| Travel adjustment range: | 4.3 | 109 mm |
| Range between the working tables: | 2 | 51 mm |
| Size of the upper pressing board: | 55.0 x 42.5 | 1397 x 1080 mm |
| Size of lower worktable: | 55.0 x 43.0 | 1397 x 1092 mm |
| Motor power: | 4HP | 5kW |
| Table Randomizer | YES | |
| Safety Light Curtain | YES | |
| Power Cord | 5' | |
| Startup Amps | 26 | |
| Operating Amps | 5 | |
| Posts | 4 | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-RH-A-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 4.3 | 109 mm |
| Range between the working tables: | 2 | 51 mm |
| Size of the upper pressing board: | 62.5 x 27.5 | 1588 x 699 mm |
| Size of lower worktable: | 62.5 x 27.9 | 1588 x 709 mm |
| Motor power: | 4HP | 5kW |
| Table Randomizer | YES | |
| Safety Light Curtain | YES | |
| CNC | FULLY AUTOMATIC | |
| Auto Feed Pinch Rollers | Pneumatic | |
| Power Cord | 5' | |
| Startup Amps | 26 | |
| Operating Amps | 5 | |
| Posts | 4 | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 60-RH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range : | 0 to 5.5 | 0 - 140 mm |
| Range between the working tables : | 2 | 51 mm |
| Size of the upper pressing board : | 63.0 x 31.5 | 1600 x 800 mm |
| Size of lower worktable : | 63.0 x 32.3 | |
| Motor power : | 10 hp | 14kW |
| Net weight : | 11023 lbs | 5000 kg |
| Video | View Here | |
| Gross weight: | 11464 lbs | |
| Dimension | 90.5 x 86.6 x 78.7 | |
| Power | 3PHASE 220V 60Hz | |
| Operating Amps | 35 | |
| Startup Amps | 180 | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Touch Screen Control Panel | Weintech | |
| Single or multiple layers of material | Yes | |
| Manual or automatic movement of the cutting head | Yes | |
| Cut counter | Yes | |
| Up down speed control | Yes | |
| Operation Manual | Electronic pdf | |
| Replacement Parts | Next Day Shipping | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 70-RH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range: | 0 to 5.5 | 0 - 140 mm |
| Range between the working tables: | 2 | 51 mm |
| Size of the upper pressing board: | 63.0 x 31.5 | 1600 x 800 mm |
| Size of lower worktable: | 63.0 x 32.3 | 1600 x 820 mm |
| Motor power: | 10 hp | 14kW |
| Net weight : | 11023 lbs | 5000 kg |
| Video | View Here | |
| Gross weight: | 11464 lbs | |
| Overall dimension: | 90.5 x 86.6 x 78.7 | 2299 x 2200 x 1999 mm |
| Power | 3PHASE 220V 60Hz | |
| Operating Amps | 35 A | |
| Startup Amps | 180 A | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Touch Screen Control Panel | Weintech | |
| Single or multiple layers of material | Yes | |
| Manual or automatic movement of the cutting head | Yes | |
| Cut counter | Yes | |
| Up down speed control | Yes | |
| Operation Manual | Electronic pdf | |
| Replacement Parts | Next Day Shipping | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 70-RH-M-J-N | |
| Standard | Metric | |
| Travel Adjustment Range: | 0 to 5.5 | 0 - 140 mm |
| Range between Working Tables: | 2 | |
| Size of upper pressing board: | 63.0 x 31.5 | |
| Size of lower worktable: | 63.0 x 32.3 | 1600 x 820 mm |
| Motor Power: | 10 HP | 14kW |
| Net Weight: | 11023 lbs | |
| Video: | View Here | |
| Gross Weight: | 11464 lbs | |
| Dimension: | 90.5 x 86.6 x 78.7 | 2299 x 2200 x 1999 mm |
| Power: | 3PHASE 220V 60Hz | |
| Operating Amps: | 35 | |
| Starting Amps: | 180 | |
| Hydraulic Fluid (not included): | ISO 68 | |
| Operation Manual: | ||
| Shipping responsibility: | Buyer | |
| Replacement Parts: | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 80-RH-A-J-Y | |
| Standard | Metric | |
| Travel adjustment range : | 0 to 5.5 | 0 - 140 mm |
| Range between the working tables : | 2 | 51 mm |
| Size of the upper pressing board : | 63.0 x 31.5 | 1600 x 800 mm |
| Size of lower worktable : | 63.0 x 32.3 | |
| Motor power : | 10 hp | 14kW |
| Net weight : | 11023 lbs | 5000 kg |
| Video | View Here | |
| Gross weight : | 11464 lbs | 5200 kg |
| Dimensions | 90.5 x 86.6 x 78.7 | 2299 x 2200 x 1999 mm |
| Power | 3PHASE 220V 60Hz | |
| Operating Amps | 35 | |
| Startup Amps | 180 | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Touch Screen Control Panel | Weintech | |
| Single or multiple layers of material | Yes | |
| Manual or automatic movement of the cutting head | Yes | |
| Cut counter | Yes | |
| Up down speed control | Yes | |
| Operation Manual | Electronic pdf | |
| Replacement Parts | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 100-RH-M-J-N | |
| Standard | Metric | |
| Travel adjustment range : | 0 | 0 mm |
| Range between the working tables : | 2 | 51 mm |
| Size of the upper pressing board : | 63.0 | 1600 mm |
| Size of lower worktable : | 63.0 | |
| Motor power : | 15hp | 21kW |
| Startup Amps | 180 | |
| Power Cord | 5' (direct Wire) | |
| Operating Amps | 35 | |
| Net weight : | 11023 lbs | 5000 kg |
| Video | View Here | |
| Gross weight : | 11464 lbs | 5200 kg |
| Dimensions | 90.5 x 86.5 x 78.5 | 2299 x 2197 x 1994 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Touch Screen Control Panel | Weintech | |
| Single or multiple layers of material | Yes | |
| Manual or automatic movement of the cutting head | Yes | |
| Cut counter | Yes | |
| Up down speed control | Yes | |
| Operation Manual | Electronic pdf | |
| Replacement Parts | Next day shipping | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-ATD-A-J-N | |
| Standard | Metric | |
| Traveling adjustment range : | 0 | 0 mm |
| Range between the working tables : | 2.3 | 58 mm |
| Size the upper pressing board : | 63.0 x 28.7 | 1600 x 729 mm |
| Size of lower worktable : | 63.0 x 29.0 | |
| Motor power : | 4 hp | 5kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 68 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Dimensions | 99 x 80 x 75 | 2515 x 2032 x 1905 mm |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 50-ATD-A-J-N | |
| Standard | Metric | |
| Max cutting force: | 50 Ton | |
| Operation Manual | ||
| Replacement Parts | Next Day Shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 80-ATS-M-J-N | |
| Standard | Metric | |
| Traveling adjustment range : | 0 | 0 mm |
| Range between the working tables : | 1.9 | 48 mm |
| Size of upper pressing board : | 63.0 | 1600 mm |
| Size of lower worktable : | 63.0 | |
| Motor power : | 10 hp | 14kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Net weight : | 15432 lbs | 7000 kg |
| Gross weight : | 16093 lbs | 7300 kg |
| Dimensions | 99 x 103 x 75 | 2515 x 2616 x 1905 mm |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 100-ATS-M-J-N | |
| Standard | Metric | |
| Traveling adjustment range : | 0 | 0 mm |
| Range between the working tables : | 6 | 152 mm |
| Size the upper pressing board : | 63.0 | 1600 mm |
| Size of lower worktable : | 63.0 | |
| Motor power : | 10 hp | 14kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' pigtail | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Net weight : | 17636 lbs | 8000 kg |
| Gross weight : | 18739 lbs | 8500 kg |
| Dimensions | 99 x 103 x 75 | 2515 x 2616 x 1905 mm |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 120-ATS-A-J-N | |
| Standard | Metric | |
| Stroke range : | 0 | 0 mm |
| Range between the working tables : | 3.0 | 76 mm |
| Size of upper cutting board : | 58.0 | |
| Size of lower worktable : | 58.0 | |
| Motor power : | 15 HP | 21kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Feeding servo motor : | 3 HP | |
| PLC touching screen : | Weview | |
| PLC : | Mitsubishi | |
| Net weight | 12125 lbs | 5500 kg |
| Gross weight : | 12566 lbs | 5700 kg |
| Dimensions | 95 x 146 x 79 | 2413 x 3708 x 2007 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 150-ATS-A-J-N | |
| Standard | Metric | |
| Traveling adjustment range : | 0 | 0 mm |
| Range between the working tables : | 1.9 | 48 mm |
| Size of upper pressing board : | 63.0 | 1600 mm |
| Size of lower worktable : | 63.0 | |
| Motor power : | 14.75 hp | 20kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Net weight : | 19841 lbs | 9000 kg |
| Gross weight : | 20943 lbs | 9500 kg |
| Dimensions | 99 x 103 x 75 | 2515 x 2616 x 1905 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Standard | Metric | |
| Max cutting force: | Up to 300 Ton | |
| Video | View Here | |
| Stroke range: | ||
| 30 Ton 63 x 19.5 Cutting Area | $ 53,575.00 | |
| 40 Ton 63 x 19.5 Cutting Area | $ 56,325.00 | |
| 50 Ton 63 x 25 Cutting Area | $ 65,950.00 | |
| 60 Ton 63 x 25 Cutting Area | $ 70,075.00 | |
| 70 Ton 63 x 30 Cutting Area | $ 77,489.00 | |
| 100 Ton 63 x 36 Cutting Area | $ 86,056.00 | |
| 100 Ton 63 x 50 Cutting Area | $ 114,251.00 | |
| 150 Ton 63 x 40 Cutting Area | $ 115,516.00 | |
| 200 Ton 63 x 40 Cutting Area | $ 141,344.00 | |
| 200 Ton 63 x 50 Cutting Area | $ 165,588.00 | |
| 250 Ton 63 x 36 Cutting Area | Call | |
| 250 Ton 63 x 40 Cutting Area | Call | |
| 300 Ton 63 x 40 Cutting Area | Call | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-BPC-A-J-N | |
| Standard | Metric | |
| Maximum Cutting Force: | 40 Ton | |
| Cutting Area: | 63.0 | |
| Video | View Here | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 50-BPC-A-J-N | |
| Standard | Metric | |
| Maximum Cutting Force: | 50 Ton | |
| Cutting Area: | 63.0 | |
| Video | View Here | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
60-DAY BUILD | IN STOCK | |
| Model Number: | 40-BPC-A-J-Y | |
| Standard | Metric | |
| Available in 40 ton, 50 ton, and 60 ton. | ||
| 40 Ton Dual Conveyor Press | Call for pricing | |
| 50 Ton Dual Conveyor Press | Call for pricing | |
| 60 Ton Dual Conveyor Press | Call for pricing | |
| Video: | View Here | |
| Contact us with the specifics of your cutting needs. | ||
60-DAY BUILD | IN STOCK | |
| Standard | Metric | |
| 50 Ton CNC Conveyor Beam Auto Sheet Feeder | $ 107,750.00 | |
| 75 Ton CNC Conveyor BeamAuto Sheet Feeder | $ 132,148.00 | |
| 100 Ton CNC Conveyor Beam Auto Sheet Feeder | $ 153,928.00 | |
| Video | View Here | |
| Optical Table Lift | ||
| Pneumatic Suction Tower | ||
| Allignment Rollers | ||
| Conveyor Press | ||
| Prices depend on table size of press | ||
| Price varies depending on the weight and size of sheet material | ||
| Contact us with specifics of your cuting needs | ||
60-DAY BUILD | IN STOCK | |
| Standard | Metric | |
| Custom Built to Cut Flooring | ||
| Max cutting force : | 200 Ton | |
| Stroke range : | 0 | 0 mm |
| Range between the working tables : | 3.0 | 76 mm |
| Size of upper cutting board : | 66.0 | |
| Size of lower worktable : | 66.0 | |
| Motor power : | 20 HP | 27kW |
| Picking equipment size : | 74 x 65 x 67 | 1880 x 1651 x 1702 mm |
| Feeding in table size : | 82 x 67 x 47 | 2083 x 1702 x 1194 mm |
| Machine size : | 147 x 110 x 87 | 3734 x 2794 x 2210 mm |
| Feeding out table size : | 67 x 74 x 47 | 1702 x 1880 x 1194 mm |
| Collecting waste equipment size : | 145 x 31 x 72 | 3683 x 787 x 1829 mm |
| Control box : | 19 x 23 x 51 | 483 x 584 x 1295 mm |
| Auto Sheet Feeder (Stack Capacity) | 400 Sheets | |
| Sheets per hour | 700 | |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Video | View Here | |
| INCLUDED EQUIPMENT | ||
| * Conveyor Discard system | * Water cooling equipment | |
| * Pneumatic auto sheet feed | * Safety light curtain | |
| * 48 pile sheet lift | * PVC die cut track | |
| * PLC touching screen : Weiview brand | * Laser location system | |
| * PLC: Mitsubishi brand | * Warning working light | |
| * Stop Limitors | ||
60-DAY BUILD | IN STOCK | |
| Model Number: | 200-BPC-A-J-Y | |
| Standard | Metric | |
| Tonnage: | 200 Ton | |
| Stroke: | 0.0 | 0 mm |
| Cutting Area: | 82.0 | |
| Automation: | Gantry Sheet Feeder | |
| Loading: | Auto Scissor Table with Photo Eye | |
| Positioning: | Roller Left Side Positioning Table | |
| Operations: | Auto & Manual | |
| Conveyor Belt: | Continuous Nylon | |
| PLC Controller: | Mitsubishi | |
| Control: | Touch Screen | |
| Cut Control: | Deadmen | |
| Light Curtains: | Front and Back | |
| Auto Picking Head: | Suction | |
| Air Compressor: | Not Included | |
| Vibration Foot Pads: | Included | |
| Die Clamps: | Manual Right Angle Brackets | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Standard | Metric | |
| Stroke range : | 3.0 | 76 mm |
| Range between the working tables : | 28.0 | 711 mm |
| Size of upper cutting board : | 60.0 x 26.0 | |
| Size of lower worktable : | 63.0 x 27.0 | |
| Motor power : | 15 HP | 21kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Net weight : | 15432 lbs | 7000 kg |
| Gross weight : | 16093 lbs | 7300 kg |
| Dimensions | 72 x 37 x 91 | 1829 x 940 x 2311 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Standard | Metric | |
| Traveling adjustment range : | 0 | 0 mm |
| Range between the working tables : | 2.0 | 51 mm |
| Size the upper pressing board : | 47.0 x 39.25 | 1194 x 997 mm |
| Size of lower worktable : | 47.0 x 40.0 | |
| Motor power : | 14.75 HP | 20kW |
| Power Requirement | 3PHASE 220V 60Hz. | |
| Startup Amps | 180 | |
| Operating Amps | 35 | |
| RPM | 1680 | |
| Power Cord | 5' | |
| Net weight : | 22046 lbs | 10000 kg |
| Gross weight : | 23148 lbs | 10500 kg |
| Dimensions | 91 x 138 x 75 | 2311 x 3505 x 1905 mm |
| Hydraulic Fluid (Not Included) | ISO 68 | |
| Operation Manual | ||
| Replacement Parts | Next day shipping | |
| Shipping Cost | Not Included | |
| Shipping Responsibility | Buyers | |
| Extended Warranty | Optional | |
| Video | View Here | |
Optional Equipment
| ||
60-DAY BUILD | IN STOCK | |
| Standard | Metric | |
| Table size: | 48.0 | 1219 mm |
| Table Type | Tslot | |
| Axis | XYZ | |
| Input Controller | RZNC-0501 DSP | |
| Stepper motor | Yes | |
| Driver | Yako | |
| Water coolant spindle | 5 HP - 4 bearing - 3.5 in | |
| Rail Guides | Hiwin 20 Linear | |
| Ball Screw | TBI 25 | |
| Power Requirement | 2232v 3Ph 60Hz | |
| Braker | 30 AMP Required | |
| Water Cooler | 2 HP | |
CJRTEC offers a wide variety of high quality industrial die cutting machines that can be customized to better suit your business needs.
Send us your die and material so we can do a test cut for you.
