60-DAY BUILD | IN STOCK | |
Model Number: | 25-TH-M-J-N | |
Standard | Metric | |
Travel adjustment range: | 0.0 | 0 mm |
Range between the working tables: | 1.8 | 46 mm |
Size of the upper pressing board: | 19.7 | 500 mm |
Size of lower worktable: | 63.0 | 1600 mm |
Motor power: | 3 HP | 4kW |
Power Requirement: | 3PHASE 220V 60Hz | |
Startup Amps: | 20 | |
Operating Amps: | 4 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Overall dimension: | 90 x 32 x 89 | 2286 x 813 x 2261 mm |
Total weight: | 4188 lbs | 1900 kg |
Video: | View Here | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Shipping Cost: | Not Included | |
Shipping Responsibility: | Buyer's | |
Extended Warranty: | Optional | |
Optional Equipment | ||
Automatic Roll feed | Light Curtain | |
Semi Auto Roll feed | Laser Marking System | |
Single Roll stand | Table Randomizer | |
Multi Roll Stand | Die Clamping System |
60-DAY BUILD | IN STOCK | |
Model Number: | 25-TH-M-J-N | |
Standard | Metric | |
Travel adjustment range: | 0.0 | 0 mm |
Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
Range between the working tables: | 1.18 | 30 mm |
Size of Traveling Head Base: | 19.7 | |
Size of lower worktable: | 63.0 | 1600 mm |
Auto Side Movement: | YES | |
Motor: | 4 HP | |
Power Requirement: | 3PHASE 220V 60Hz | |
Startup Amps: | 20 | |
Operating Amps: | 4 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Overall Dimension: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
Crate Size: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
Total weight: | 3747 lbs | 1700 kg |
Video: | View Here | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Shipping: | Not Included | |
Shipping Responsibility: | Buyer's | |
Extended Warranty: | Optional | |
Optional Equipment | ||
Automatic Roll feed | Light Curtain | |
Semi Auto Roll feed | Laser Marking System | |
Single roll stand | Table Randomizer | |
Multi Roll Stand | Die Clamping System |
60-DAY BUILD | IN STOCK | |
Model Number: | 25-TH-M-J-Y | |
Standard | Metric | |
Travel adjustment range: | 1.0 | 25 mm |
Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
Range between the working tables: | 1.18 | 30 mm |
Size of Traveling Head Base: | 19.7 | |
Size of lower worktable: | 82.0 | 2083 mm |
Motor: | 3 HP | |
Power Requirement: | 3PHASE 220V 60Hz | |
Startup Amps: | 20 | |
Operating Amps: | 4 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Overall Dimension: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
Crate Size: | 98 x 29 x 84 | 2489 x 737 x 2134 mm |
Total weight: | 3918 lbs | 1777 kg |
Video: | View Here | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Shipping Cost: | Not Included | |
Shipping Responsibility: | Buyer's | |
Extended Warranty: | Optional | |
Optional Equipment | ||
Automatic Roll feed | Light Curtain | |
Semi Auto Roll feed | Laser Marking System | |
Single Roll stand | Table Randomizer | |
Multi Roll Stand | Die Clamping System |
60-DAY BUILD | IN STOCK | |
Model Number: | 25-TH-A-J-N | |
Standard | Metric | |
Head Size: | 20.0 | 508 mm |
Lower Table Size: | 63.0 | 1600 mm |
Travel adjustment range: | 1.2 - 6.0 | 30 - 152 mm |
Up and Down Speed: | 4.75 in/s | 0.4 ft./s |
Side to Side Speed: | 9 in/s | 0.75 ft./s |
Motor Size: | 4 HP | 5kW |
Power Requirements: | 220v 3Phase 60Hz | |
Startup Amps: | 15 | |
Running Amps: | 5 | |
RPM: | 1680 | |
Power Cord: | 10 ft | |
Overall Dimensions: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
Shipping Dimensions: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
Weight: | 4630 lbs | 2100 kg |
Video: | View Here | |
Operation Manual: | ||
Replacement Parts: | Next Day Shipping | |
Extended Warranty: | Optional |
60-DAY BUILD | IN STOCK | |
Model Number: | 25-TH-A-J-Y | |
Standard | Metric | |
Range between the working tables: | 1.18 | 30 mm |
Travel adjustment range: | 0.0 | 0 mm |
Size of Traveling Head Base: | Diameter of 16 .0 | |
Size of lower worktable Depth: | 62.0 x 19.5 | |
Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
Side to Side Speed: | 2 - 9 in/s | 2.42 ft./s |
Feeding Speed: | 3/4 - 3.5 in/s | |
Motor: | 4 HP | |
Power Requirement: | 3PHASE 220V 60Hz | |
Startup Amps: | 20 | |
Operating Amps: | 4 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Total weight: | 4630 lbs | 2100 kg |
Overall Dimension: | 87.0 x 27.5 x 80.7 | 2210 x 699 x 2050 mm |
Crate Size: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
Video: | View Here | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Extended Warranty: | Optional | |
Key Features | ||
Single or Multi layer cutting | Programmable automatic head movement | |
Auto roll advancement | Programmable Nesting feature | |
Cutting pad lock | Cut and hold feature for heat press capabilities | |
High speed movement | Fast magnetic die setup feature | |
Light Curtain | Up down speed control | |
Optional Equipment | ||
Automatic Roll feed | Light Curtain | |
Semi Auto Roll feed | Laser Marking System | |
Single Roll stand | Table Randomizer | |
Multi Roll Stand | Die Clamping System |
60-DAY BUILD | IN STOCK | |
Model Number: | 30-TH-M-J-N | |
Standard | Metric | |
Travel adjustment range: | 0.0 | 0 mm |
Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
Range between the working tables: | 1.18 | 30 mm |
Size of traveling head: | 22.5 x 22.5 | 572 x 572 mm |
Size of lower worktable: | 63.0 x 23.5 | 1600 x 597 mm |
Auto Side Movement: | YES | |
Motor power: | 3 HP | 4kW |
Power Requirement: | 3PHASE 220V 60Hz | |
Startup Amps: | 20 | |
Operating Amps: | 4 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Overall dimension: | 91 x 42 x 77 | 2311 x 1067 x 1956 mm |
Crate Size: | 89 x 29 x 84 | 2261 x 737 x 2134 mm |
Total weight: | 3747 lbs | 1700 kg |
Video: | View Here | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Shipping Cost: | Not Included | |
Shipping Responsibility: | Buyers | |
Extended Warranty: | Optional | |
Optional Equipment | ||
Automatic Roll feed | Light Curtain | |
Semi Auto Roll feed | Laser Marking System | |
Single roll stand | Table Randomizer | |
Multi Roll Stand | Die Clamping System |
60-DAY BUILD | IN STOCK | |
Model Number: | 35-TH-M-J-N | |
Standard | Metric | |
Travel adjustment range: | 0.0 | 0 mm |
Up and Down Speed: | 0.12 m/s | 0.39 ft./s |
Range between the working tables: | 1.2 | 30 mm |
Size of traveling head: | 19.5 | 495 mm |
Size of lower worktable: | 62.0 | 1575 mm |
Auto Side Movement: | YES | |
Motor power: | 4 HP | 5kW |
Power Requirement: | 3PHASE 220V 60Hz | |
Startup Amps: | 20 | |
Operating Amps: | 4 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Fluorescent Table Light: | Yes | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Overall dimension: | 79 x 29 x 80 | 2007 x 737 x 2032 mm |
Crate Size: | 86 x 35 x 86 | 2184 x 889 x 2184 mm |
Total weight: | 5291 lbs | 2400 kg |
Video: | View Here | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Shipping Cost: | Not Included | |
Shipping Responsibility: | Buyer's | |
Extended Warranty: | Optional | |
Optional Equipment | ||
Automatic Roll feed | Light Curtain | |
Semi Auto Roll feed | Laser Marking System | |
Single roll stand | Table Randomizer | |
Multi Roll Stand | Die Clamping System |
60-DAY BUILD | IN STOCK | |
Model Number: | 35-TH-A-J-N | |
Standard | Metric | |
Range Between Working Tables: | 1.0 | 25 mm |
Travel Adjustment Range: | 0.0 | 0 mm |
Size of Travel Head: | 19.5 | 495 mm |
Size of Lower Work Table: | 63.0 | |
Motor Power: | 4 HP | 5kW |
Power Requirements: | 3Phase 220v 60Hz | |
Startup Amps: | 42 | |
Operating Amps: | 14 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Hydraulic Fluid (not included): | ISO 68 | |
Weight | 0 kg | |
Dimension | ||
Video: | View Here | |
Operation Manual: | ||
Replacement Parts: | Next Day Shipping | |
Extended Warranty: | Optional |
60-DAY BUILD | IN STOCK | |
Model Number: | 50-TH-A-J-N | |
Standard | Metric | |
Travel adjustment range: | 0.0 | 0 mm |
Range between working tables: | 1.0 | 25 mm |
Size of traveling head: | 24.0 | 610 mm |
Size of lower work table: | 72.0 | 1829 mm |
Motor power: | 7.25 HP | 10kW |
Power Requirement: | 3PHASE220V60Hz. | |
Startup Amps: | 75 | |
Operating Amps: | 19 | |
RPM: | 1680 | |
Power Cord: | 5' | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Net weight(Dry): | 8378 lbs | 3800 kg |
Shipping weight : | 8819 lbs | 4000 kg |
Dimension | 102 x 71 x 87 | |
Video: | View Here | |
Training Video: | Yes | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Shipping Cost: | Not Included | |
Shipping Responsibility: | Buyers | |
Extended Warranty: | Optional | |
Key Features | ||
Single or Multi layer cutting | Die Clamping System | |
Auto roll advancement | Up down speed control | |
Cutting pad lock to prevent pad warping | ||
Programmable automatic head movement. | ||
Programmable Nesting feature | Light Curtain | |
Cut and hold feature for heat press capabilities | ||
High speed movement | ||
Optional Equipment | ||
Single Roll stand | Laser Marking System | |
Multi Roll Stand | Table Randomizer | |
60-DAY BUILD | IN STOCK | |
Model Number: | 70-TH-M-J-N | |
Standard | Metric | |
Table size: | 63.0 | 1600 mm |
Head size: | 24.0 | 610 mm |
Distance between tables: | 0.0 | |
Travel adjustment range: | 0.0 | 0 mm |
Motor: | 7.25hp | |
Power Requirement: | 220v 3ph 60Hz | |
Startup Amps: about | 25A | |
Operating Amps: about | 18A | |
RPM: | 970 r/m | |
Shipping weight: | 16534 lbs | 7500 kg |
Dimensions: | 0 mm | |
Video: | View Here | |
Training Video: | Yes | |
Operation Manual: | ||
Replacement Parts: | Next day shipping | |
Hydraulic Fluid (Not Included): | ISO 68 | |
Shipping Cost: | Not Included | |
Shipping Responsibility: | Buyer's | |
Extended Warranty: | Optional |
60-DAY BUILD | IN STOCK | |
Model Number: | 75-TH-A-J-N | |
Standard | Metric | |
CNC Auto Feed Table size: | 63.0 | |
Head size: | 24.0 | 610 mm |
Distance between tables: | 0.0 | |
Travel adjustment range: | 0.0 | 0 mm |
Motor: | 7.25 HP | |
Power Requirement: | 220v 3ph 60Hz | |
AUTO FEED SYSTEM | ||
Abrasive Steel Rollers: | Diameter of 4.0 | |
(Drive motor)Servo motor: | 1 HP | |
Pneumatic Cyl 6.25 x 4QGS2 | 150 lbs Down Pressure | |
Opening between rollers: | 2 | |
Startup Amps: about | 25A | |
Operating Amps: about | 18A | |
RPM: | 970r/m | |
Shipping weight: | 16534 lbs | 7500 kg |
Dimensions: | 0 mm | |
Video: | View Here | |
Training Video: | Yes | |
Operation Manual: | ||
Hydraulic Fluid (Not Included): | ISO 68 | |
Replacement Parts: | Next day shipping | |
Shipping Cost: | Not Included | |
Shipping Responsibility: | Buyer's | |
Extended Warranty: | Optional | |
Optional Equipment | ||
Single Roll stand | Laser Marking Sys | |
Multi Roll Stand | 480v motor | |
360 degree swivel head | ||
